Simple design, high-quality PC material, black resin glue inside, practical waterproofing, anti-metal shielding, and card reader mutual interference capabilities, providing you with the finest experience. High-end receiver circuit design and industrial-grade embedded microcontrollers with high reception sensitivity, low cost, and high performance. It has a buzzer, an LED indication, and an output protection feature.
It has a basic and obvious construction, is easy to install and use, and is excellent for various big access control systems. Fully sealed design, moisture-proof and dust-proof, working environment temperature range of -25°C to 75°C, may be placed in outdoor and other difficult situations, no mechanical wear, and durable. Access control, time and attendance systems, and door panels are all widely employed to provide more dependable security protection.
DIMENSION
APPLICATION
- Residential Quarters
- Office Building
- Factory
- Parking IoT
- Shopping Arcade
- Hotel, Apartment
SPECIFICATIONS
|
Product Name
|
RS485 RFID Wall Mount PLC MODBUS Card Reader 13.56Mhz
|
|
Material
|
ABS
|
|
Communication interface
|
Serial port TTL or RS485
|
|
Working voltage
|
DC9~12V, Support Custom
|
|
Working temperature
|
-25℃ – 70 ℃
|
|
Size
|
113mm×73mm×16mm
|
|
Color
|
Black
|
|
Frequency
|
13.56Mhz ,125khz (Option )
|
|
Protocol
|
ISO14443A
|
|
Baud rate
|
Optional, 9600bit / s by default
|
SHIPPING LIST
- 1 x RS485 RFID Reader
